CoEAMT

4 Axis Filament Winding

Make: Vashishtha Research || Model: Carbon Chakra

• Thermoset Winding
• Thermoplastic Winding
• Type IV and Type V pressure vessels

5-Axis CNC Wire-cut EDM

Make: Electronica || Model: Enova 2S

• Submerge type 5-axis CNC controller with TURBO motion control technology.
• Machining of Poly – Crystalline Diamond.
• Auto wire threading facility available.
• Multistage water filtration facility available.

UTM

Make: Zwick Roell || Model: Kappa 100 SS-CF

• State-of-the-art 50 kN tensile-compression-fatigue-creep testing unit along with non-contact video extensometer.
• Specimen tensile testing at 1200 °C.
• Low cycle creep fatigue tests under strain.

Hybrid Additive Manufacturing

Make: Optomec || Model: LENS 860 Hybrid Machine

• 5-axes CNC machine tool with subtractive machining & direct laser deposition based additive system.
• MasterCAM Mill 3D professional software.
• Equipped with Ytterbium Fiber laser of 2 kW.

CNC Machining Centre

Make: DMG MORI || Model: DMU 50

• Industry 4.0 enabled with accuracy up to < 6 µm.
• Optimized ergonomics and design.
• Larger machining compartment.
• Improved cooling in all drives and guides.
• Direct path measuring system in all five axes.

CNC Turning Centre

Make: Ace Designers || Model: LT 20 XL

• Servo motor controlled 2 axis CNC Turning centre of SIEMENS 828 D controller.
• High precise in positioning and repeatability.
• Electric spindle with high torque.
• High spindle rotational speed.
• Equipped with CAD-CAM (CADEM) software for autocode generation.

CNC Trainer Lathe

Make: HYTECH || Model: HPL 100

• This 2 axis CNC Lathe is for Semiproduction purpose.
• High precise in positioning and repeatability.
• CNC controller: FANUC Oi Mate-TF.
• Equipped with CAD-CAM (BoB CAD & CAM) software for autocode generation.

CNC Mill Trainer

Make: HYTECH || Model: SPM 250

• Servo motor controlled semiproduction type 3 axis CNC Mill.
• High precise in positioning and repeatability.
• CNC controller: FANUC Oi Mate-MF.
• Equipped with CAD-CAM (BoB CAD & CAM) software for autocode generation.

Robotic MIG

Make: KUKA AND FRONIUS || Model: KUKA: KR 14 R1420, FRONIUS: TPS 500i CMT

• Current, voltage and force sensors for process monitoring.
• High precise in positioning and repeatability.
• Flow level, flow rate and pressure sensors for health monitoring.

Robotic TIG

Make: KUKA AND FRONIUS || Model: KUKA: KR 14 R1420, FRONIUS: Magicwave 5000

• Current and voltage sensors for process monitoring.
• High precise in positioning and repeatability.
• Flow level, flow rate and pressure sensors for health monitoring.

3-Axis Job Positioner

Make: KUKA || Model: KP3 V2H 250

• Payload: 250 Kg, Tool radius: 500 mm to 1000 mm, Distance between face plates: 1600 mm - 3000 mm.
• Stationed in front of MIG and TIG robots for handling the jobs.

Robotic Spot Welding

Make: KUKA AND NASH AUTOMATION || Model: KUKA: KR 210 R2700 Ex. NASH AUTOMATION: IMF 1000A

• Current, voltage and force sensors for process monitoring.
• High precise in positioning and repeatability.
• Real-time monitoring and control of spot welding.

Robotic Laser Welding and Cladding

Make: KUKA AND IPG || Model: KR 30 R2033, YLS 6000 K

• Current, voltage and force sensors for process monitoring.
• High precise in positioning and repeatability.
• 6 kW fiber laser with infrared and optical cameras for process monitoring.
• Mounted with cladding head.

CNC Simulator

Make: FANUC || Model: CNC Simulator

• This simulator is one of the CNC training kits, where students can get the visual experience of the created program.
• This can be switchable from Lathe to Mill and vice versa.
• This is very much easy to carry.
• Equipped with NC guide (FANUC simulator) software.

Computer Integrated Manufacturing Facility

Make: MTAB

• CNC Milling and CNC Turning units.
• Inspection / quality control – vision control system.
• Vibration, temperature and proximity for sensing manufacturing data.
• Data storage, retrieval, manipulation and presentation by using IoT gateway.

5 MP Blue Light Scanner

Make: Zeiss || Model: Zeiss Comet 5M

• Blue LED technology scans many surface types.
• 5 million points per scan.
• 5 interchangeable lenses.
• Fast scanning, high accuracy and portable.
• Rotary table for automatic scanning.

Sample Cutting Machine

Make: Struers || Model: Discotom

• Automatic cut-off machine with intelligent feed control.
• Variable spindle speed and automatic feed.
• Automatic cleaning facility.
• Can cut very hard materials.

Hot Mounting Press

Make: Struers || Model: Citopress 15

• Electro-hydraulic hot mounting press.
• Fast heating available.
• Automatic detection of cylinder dimension.
• Automatic dosing system for faster filling.

Grinding & Polishing Machine

Make: Struers || Model: LaboPal 30

• Semi-automatic grinding and polishing machine with stable sample preparation facility.
• Automatic water ON/OFF system.
• Easy drying and cleaning facility.

Electrochemical Station

Make: Gamry || Model: 1010E

• The system can be utilized for electrochemical corrosion, battery testing, fuel cell testing, and physical electrochemistry.
• A wide range of current ranging from 10 nA to 1 A with a minimum current resolution of 3.3. fA.

Stereozoom Microscope

Make: Carl Zeiss || Model: Discovery V20

• Appochromatically corrected optics.
• Touch screen controls for magnification and resolution, depth of field and object field.

Metallurgical Microscope

Make: Leica Microsystems || Model: DMi8A

• Intelligent automation.
• Imaging contrast technique.
• Ultra-contrast 3D illumination.
• Sample re-position capacity up to 20 nm.

High Resolution FESEM

Make: Tescan || Model: Tescan MIRA 3 LMH

• Schottky emitter for high-resolution.
• Unique wide field optics.
• Real-time in-flight beam tracing.
• 5-axis fully motorized compucentric stage.

Table Top XRD

Make: Rigaku || Model: MiniFlex

• 6th gen. design with factory aligned goniometer system.
• Incident beam variable slit.
• Phase identification, quantification with crystallinity percentage, crystallite size and strain etc.

Robot-assisted Micro Friction Stir Welding Machine

Make: KUKA || Model: KR 500 R2830 MT

• Industry 4.0 enabled, 500 Kg payload robot with a reach of 2830 mm.
• Suitable for micro-size jobs & dissimilar materials.
• 6D force sensor for monitoring forces and torque in all three directions.

Foundry Robot

Make: KUKA || Model: KR 180 R2100 nano F

• Payload: 180 Kg , Reach: 2100 mm maximum.
• Number of controlled axes: 6.
• Pose repeatability: ± 0.05 mm.
• KR C4 controller. Offline simulation software.

COMSOL Multiphysics Modeling Software

COMSOL

• Comes with an “Application Builder” which can be used to develop independent domain-specific applications with customized user-interface.

Robotic 3D Laser Scanning Structural Vibration Test Station

Make: Polytec || Model: PSV-500-3DH

• 3D laser scanning vibrometers mounted on a multi-axis industrial robot.
• Payload= 90 Kg & controlled axes= 6 + 1 (linear track of 4 m length).
• Software for incorporating FE geometry, external sensor data, & modal analysis.
• Frequency range: 0-100 kHz.

Thermal Imager

Make: FLIR || Model: E-95

• High temperature ranges up to 1500°C.
• A built-in mic for voice annotation, and report generation features.
• A touch screen with a 160° viewing angle.

Acoustic Holography

Make: B & K || Model: 9712-W-FEN

• Complete system for real-time noise source identification (NSI) that can be used for both stationary and non-stationary measurements.
• Consists of a hand-held array, LAN-XI data acquisition hardware, BK Connect software.

Power Sensor

Make: Montronix || Model: PS-200-NG

• Measures the input of effective electrical power of spindle and axle drive.
• Useful for monitoring of feeder and spindle drives, detection of broken tools, detection of tool wear etc.
• Spectra unit for process monitoring.
• A display screen for visualizing the signal.
